155-32602海爾曼太通HellermannTyton扎帶卡扣FT6LG.M.St.Aufn.II
| Anti rotation (Yes / No) | NO |
| Application 2 | For Yazaki connector 7282-6458-40, 7229-1127, 7282-6444-60, 7282-34444-40, 7282-6455-40, 7229-1449-30, 7229-1820-90, 7229-4220-30, 7229-4445-40, 7282-6443-40 |
| Colour | Black (BK) |
| Fixation Method | Fir Tree |
| Fixing Hole Shape | Circular |
| Pack Cont. | 500pcs. |
| Package Quantity per | bag |
| PART DESCRIPTION | FT6LG.M.St.Aufn.II-PA66HIRHS-BK |
| Product Group | Connector Clips for round holes |
| Disc ? | 16mm |
| for Hole ? (FH) | 6.5 - 7.0 mm |
| for Panel Thickness min - max | 0.8 - 1.5 mm |
| Height (H) | 17.3mm |
| Length (L) | 27mm |
| Length of Fir Tree | 11.1mm |
| Panel Thickness max. | 0.75 - 5.0mm |
| Width (W) | 16mm |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 HB |
| Hazardous good | No |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| Operating Temperature - °C | -40 °C to +105 °C |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Recognized (US and Canada) | No |
